How many overhead lighting fixtures can I connect to an MX Series system?

This article discusses overhead lighting for MX Series systems.

Product applicability

The following products are discussed in this article:

  • MX Series: R920-MX

All MX Series systems contain a built-in DC relay output on the power module circuit board. This output is capable of up supplying up to 5 A @ 12 VDC. This requirement limits the capability to one overhead fixture per MX Series power module for solar-powered systems.

The MX 400 AC-powered system can support multiple overhead lighting fixtures with our AC relay kit.
